The CL1000N is a LCD KVM console that features an integrated 19” LCD panel, full keyboard, and touchpad in a 1U rackmountable housing. This model provides convenient ‘at the rack’ console access to KVM switches already installed at your site.
- Integrated KVM console with a 19" LCD monitor in a sliding housing with top and bottom clearance for smooth operation in a 1U high system rack
- LCD module rotates up to 115˚ for a more comfortable viewing angle
- Improved design – optional single person installation kit
- Compatible with most KVM switches
- Internal power supply
- High video resolution:
• Up to 1280 x 1024 @75Hz
• Supports DDC, DDC2, DDC2B
• DDC emulation of the LCD monitor – Video settings of attached computers are automatically adjusted for optimal output to the LCD monitor
Spesifikasi
| Connectors | Console Ports | Keyboard/Video/Mouse | 1 x SPHD-15 Female (Yellow) |
| Power | 1 x 3-prong AC Socket | ||
| Switches | LCD Adjustment | 4 x Pushbuttons | |
| LCD Power | 1 x Pushbuttons | ||
| LEDs | CPU | 1 (Green) | |
| Num Lock | 1 (Green) | ||
| Caps Lock | 1 (Green) | ||
| Scroll Lock | 1 (Green) | ||
| Emulation | Keyboard/Mouse | PS/2, USB (with 2L-52xxUP USB KVM cable) | |
| Video | 1280 x 1024 @ 75 Hz ; DDC2B | ||
| I/P Rating | 100-240 VAC; 50/60 Hz; 1A | ||
| Power Consumption | 120 V, 21 W; 230 V, 24 W | ||
| Environment | Operating Temp. | 0 - 50˚C | |
| Storage Temp. | -20 - 60˚C | ||
| Humidity | 0 - 80% RH, Non-condensing | ||
| Physical Properties | Housing | Metal + Plastic | |
| Weight | 12.30 kg | ||
| Dimensions ( L x W x H ) | 58.52x48.30x4.40cm | ||
Untuk harga anda bisa lihat di link berikut
Semoga kami dapat membantu semua kebutuhan anda, Terima kasih
